30kV Medium voltage (GS-MV) Electrical Insulation Rubber Mat, Model: GS-MV, Class 2, 30kV

A) Product Name

Model: GS-MV (Medium Voltage) Corrugated Switchboard Matting / Non-Conductive Switchboard Mat / Dielectric / Medium Voltage Insulation Rubber Mat

B) Raw Material

NATURAL RUBBER (NR) BASED POLYMER

C) Purpose

Switchboard matting is a non-conductive, high-density rubber compound engineered to prevent electric shock around high-voltage equipment.

The non-conductive rubber compound creates an insulating barrier between the electrical source and the ground.

D) Scope

Our GS-MV is tested according to IEC61111:2009 Clause 5.6.4.3 under IEC 61111:2009 Class 2, Ideal for Dielectric Voltage / Withstand Voltage: 30,000 VAC and Recommended Maximum use Voltage: 17,000 VAC

E) Characteristics

1) Brand Name: GSE™

2) Model: GS-MV Switchboard Matting / Medium Voltage Insulation Rubber Mat

3) Top Surface—Anti-slip corrugated. The anti-slip corrugated surface provides a safe working environment, and the pattern surface “grabs” the bottom of footwear, improving traction and safety.

4) Colour: Black

TESTED BY THREE (3) ACCREDITATED BODIES

5) Test Certificate IEC61111:2009 Class 2 Withstand Voltage 5.6.4.3: Tested by 3rd Party Accredited Laboratory (TNB Labs)

6) Test Certificate ASTM D635: 2018 - Standard Test Method for Rate of Burning and/or Extent and Time of Burning of Plastics in a Horizontal Position: Tested by 3rd Party Accredited Laboratory (SIRIM)

7) Test Certificate RoHS Directive Commission Directive (EU) 2015/863: Tested by 3rd Party Accredited Laboratory (SGS) RoHS 1 & 2

8) Product Compliance Status:-

A) BS EN 61111 Clause 5.6.4.3 Class 2, Voltage Withstand Test (TNB Lab)

B) Comply with EU RoHS 1 & 2 Standards (RoHS 2011/65/EU) (SGS)

C) Test Certificate ASTM D635: 2018 (SIRIM)

SPECIFICATIONS:

1) Nominal Thickness: 5mm

A) Brand: GSE™,  Model: GS-MV, Switchboard Matting,

(Black colour) , 5mm Tk x 1,000mm (1 m ) Width x 6,000mm ( 6 m ) Length / roll
